Studio Stereo Microphone Techniques: An Overview of the Top 4 Methods Used
In the realm of music recording, using multiple microphones can add an extra dimension to your productions, particularly when it comes to capturing the intricate sounds of an acoustic guitar. Here, we delve into some common stereo microphone techniques that are frequently used in recording studios for accurate instrument positions, room ambience, and achieving an even tone and frequency balance across the stereo image.
X-Y Technique (Coincident Pair)
The X-Y technique is a popular choice, employing two directional microphones placed with capsules as close as possible, typically angled at 90 degrees apart. This setup produces a clear stereo image with excellent localization and minimal phase issues. Adjusting the mutual angle can widen the stereo recording angle, providing a better spread while maintaining good timbral balance.
ORTF Technique
The ORTF (Office de Radiodiffusion-télévision Française) technique is another favoured approach, using two cardioid microphones spaced about 17 cm apart and angled at 110 degrees. This setup mimics human ear spacing and provides a natural stereo image, combining time and amplitude differences to enhance realism. The ORTF technique is particularly useful for acoustic guitar, adding a sense of space without excessive room ambience, while maintaining tonal evenness.
Spaced Pair (A-B) Technique
The spaced pair technique involves two omnidirectional or cardioid mics placed several inches to feet apart, often matching the guitar body length for natural balance. This approach captures a wider stereo image with more room ambience due to spacing and time arrival differences. However, there is a risk of phase issues if spacing and pickup levels aren’t carefully managed.
Blumlein Pair
The Blumlein pair uses two figure-8 microphones placed coincidentally at 90 degrees, capturing direct sound and ambience with excellent stereo depth. This setup produces a smooth and balanced tone; lowering the mutual angle slightly can increase the stereo recording angle to achieve a wider stereo spread.
Additional Recording and Placement Tips
- Position microphones at roughly the guitar body length distance for balanced tonal capture of the instrument’s resonant frequencies without excessive boominess from the sound hole.
- Avoid placing microphones too close to reflective surfaces or too far from the instrument to prevent muddy or hollow tones due to too much room sound or comb filtering. Applying the 3-to-1 rule helps minimize phase issues when using multiple microphones.
- Use a combination of close mics (for direct instrument sound) and room mics (for ambience) with appropriate EQ to blend tonal characteristics. For instance, room mics may be EQ’ed differently to complement the close mics and prevent masking.
In summary, the X-Y and ORTF techniques are preferred for precise stereo imaging and tonal balance when close to an acoustic guitar, while spaced pairs and Blumlein arrays add more natural ambience and spaciousness. Adjusting mic angles and distances according to the guitar’s size and room characteristics helps achieve an even tone and frequency balance across the stereo field.
[1] Blauert, J. (1997). Spatial Hearing: Psychophysics and Technology of Environmental Audio. Springer. [2] Freed, A. (2013). Sound Reproduction: Loudspeakers and Rooms. Focal Press. [3] Ruiz, R. (2003). Mixing Secrets for the Small Studio. Focal Press. [4] Tcherepnin, V. (2010). Mixing with your Mind: The Art and Science of Sound Recording. Hal Leonard. [5] Toole, F. (2008). Stereo Microphone Techniques: Principles and Applications. Focal Press.
- To capture the intricate sounds of an acoustic guitar using multiple microphones, the X-Y technique is a popular choice, placing two directional microphones closely with capsules angled at 90 degrees apart.
- In the realm of music recording, the ORTF technique is another favored approach, with two cardioid microphones spaced about 17 cm apart and angled at 110 degrees, offering a natural stereo image that's useful for acoustic guitars.
- For a wider stereo image with more room ambience, the spaced pair technique can be employed, utilizing two omnidirectional or cardioid mics positioned several inches to feet apart, often matching the guitar body length for natural balance.
- Experimenting with the Blumlein pair, two figure-8 microphones placed coincidently at 90 degrees, gives a smooth and balanced tone, suitable for capturing both direct sound and ambience.
- Positioning microphones approximately at the guitar body length distance can help achieve a balanced tonal capture of the instrument’s resonant frequencies while avoiding excessive boominess from the sound hole.
