Guide on Chipping a 0.5mm Ball Grid Array (BGA)
Performing a 0.5mm BGA breakout for high-density interconnect (HDI) technology requires meticulous attention to pad design, annular rings, drill-to-copper spacing, and overall PCB design rules to ensure reliable manufacturability and electrical performance.
1. BGA Pad and Annular Ring Calculation
When dealing with a 0.5mm pitch BGA ball, the typical ball diameter is about 0.25mm (±0.05mm), but it's essential to check the exact package tolerances. The pad diameter on the PCB should be slightly larger than the ball diameter to provide a good solder joint—commonly 0.25 to 0.30mm for a 0.5mm pitch ball.
The annular ring (the copper ring around the drilled hole in a via or pad) typically should be at least 0.1mm minimum, but for HDI and reliable manufacturing, 0.15mm to 0.2mm is recommended. This is crucial to avoid breakout or lift-off during processing. The smallest drill recommended for breakout vias in HDI for 0.5mm pitch BGA is usually about 0.15 to 0.20mm diameter to keep the via small enough to fit between pads yet manufacturable.
2. Drill-to-Copper Spacing and Design Rules
Minimum spacing from the drill hole edge to the edge of adjacent copper features often is set at 0.1mm or greater in HDI designs to avoid solder bridging and ensure proper isolation. For HDI PCBs, advanced fabrication allows finer features, but the IPC standards recommend following process capabilities to avoid shorts.
The clearance between traces routed out from breakout vias or pads must also obey minimum width and spacing rules, typically ≥0.10mm line width and spacing for high-density designs. Solder mask dams should be maintained with at least 0.1mm clearance to prevent solder bridging.
3. Breakout Strategy for 0.5mm BGA
Usually, a via-in-pad approach is used for very fine pitch BGAs (e.g., 0.5mm), whereby microvias are placed directly in the breakout pads to fan out signals to inner layers. Microvias for breakouts (<0.15mm drill) are filled and plated over to provide a flat surface for assembly. For breakout routing, a fan-out of at least 3 routing channels is recommended (meaning spacing breaks to route 3 traces between each pad on breakout layers).
4. General Design Rules for HDI and Fine BGA Breakout
| Parameter | Typical Value for 0.5mm BGA Breakout (HDI) | |--------------------------|---------------------------------------------| | BGA ball diameter | ~0.25 mm | | Pad diameter | 0.30 mm (0.25-0.35 mm range depending on fab) | | Annular ring width | ≥0.15mm | | Drill size (breakout vias) | 0.15 - 0.20 mm | | Drill-to-copper spacing | ≥0.10 mm | | Trace width and spacing | ≥0.10 mm (depends on fab capabilities) | | Solder mask clearance | ≥0.10 mm | | Via-in-pad usage | Recommended, with filled and plated microvias |
Additional Notes:
- The IPC-A-600 and IPC-7351 standards provide guidelines for BGA pad design, solder mask openings, annular rings, and breakout requirements.
- Ensure your PCB fabricator confirms their minimum drill sizes and spacing rules before finalizing your design—they can vary.
- Use controlled impedance and careful layer stackup to maintain signal integrity when routing breakout traces.
- In depanelization and handling, ensure no mechanical stress damages the delicate BGA and breakout vias.
This balance of small annular rings, tight drill-to-copper spacing, microvia in pad technology, and strict design rules is the key to successfully perform 0.5mm BGA breakout for high-density interconnect PCBs. The solder mask and solderpaste for a BGA will also be 10.68 mils, and the copper spoke between the drills on a .5mm BGA will be 3 mils wide. The board must be 62 mils or less thick and have no more than eight layers for the drill-to-copper spacing provided to work. The drill size for a BGA is 6 mils.
